Kubota M7-154 Specs, Features & Field-Ready Buyer Guide

The Kubota M7-154 is a row-crop tractor built for operators who want one machine that can run PTO-heavy implements, handle hydraulic-demanding tools, and still stay comfortable for long days in the field. The big advantage of this model is “work rate”: 120 PTO horsepower, CCLS hydraulics, and drivetrain options that let you build it for either straight efficiency (CVT) or direct, repeatable speed steps (PowerShift).

---

Kubota M7-154 Quick Specs

• Category / Series: Row-crop tractor, M7-4 Series
• Model years: 2023–
• Engine gross horsepower: 148 HP
• PTO horsepower: 120 HP
• Drive: 4WD
• Cab: Standard with A/C; cab suspension options listed
• Hydraulics: CCLS, 29 gpm
• Rear remotes: Max 4 (Deluxe) / 5 (Premium)
• 3-point hitch: Category 3 / 3N
• Lift @ 24 in behind: 11,797 lb
• Rear lift (ends): 20,723 lb
• PTO: Rear independent 540/1000; front PTO 1000
• Fuel / DEF: 87 gal fuel, 10 gal DEF

---

Engine

This tractor uses a 6.1L turbocharged intercooled diesel designed for sustained load—exactly what you want for long PTO days, heavy draft, and multi-function hydraulic work.

Engine specs

• Engine model: V6108 (Tier 4)
• Displacement: 374 cu in (6124 cc)
• Rated speed: 2100 rpm
• Boost power: +20 HP (listed)

---

Transmission (choose the “personality” of the tractor)

This is where the M7-154 can be tuned for your operation: repeatable gear steps for consistent pulling, or smooth CVT speed control for precision work.

Semi-PowerShift (30×15) — practical & predictable

• Forward / reverse speeds: 30 / 15 (listed)
• Shuttle: electro-hydraulic shuttle

CVT — smooth field speed control

• Transmission option: CVT listed alongside PowerShift

Optional creeper

• Creep speeds: 54 forward / 27 reverse (optional)

---

Hydraulics & 3-Point Hitch

If you’re running modern implements, the headline is 29 gpm CCLS—fast response, strong flow, and better multi-function performance when multiple circuits are active.

• Hydraulic type: Closed center, load sensing (CCLS)
• Pump capacity: 29 gpm (110 l/min)
• Control system: electronic draft / lower link sensing
• 3-point: Category 3 / 3N
• Lift @ 24”: 11,797 lb
• Lift at ends: 20,723 lb

---

PTO

• Rear PTO: independent; 540/1000
• Front PTO: 1000

---

Dimensions, Weight & Tires

These are the key “fit/transport” numbers for planning sheds, trailers, and general footprint.

• Wheelbase: 107 in
• Overall length: 188 in
• Overall height: 119 in
• Shipping weight: 14,546 lb
• Standard tires: Front 14.9R28 / Rear 18.4R38

---

Loader option (for mixed farm + handling)

If your M7-154 will spend time doing feed, bales, pallets, or bulk material, the loader pairing is a major part of the build.

LM2606 Loader

• Lift (full height at pin): 5,776 lb
• Breakout (at pin): 9,069 lb
• Max height (at pin): 167 in
• Bucket width: 96 in

---

Kubota M7-154 FAQ

How much PTO horsepower does the M7-154 have?

It’s listed at 120 PTO horsepower.

What hydraulic system does it use?

A closed-center, load-sensing (CCLS) system with 29 gpm pump capacity is listed.

What hitch category is the M7-154?

It’s listed with a Category 3 / 3N 3-point hitch.

Which loader is commonly paired with it?

The LM2606 loader is listed, with 5,776 lb lift at full height (pin).
