JCB 555-70 Telehandler

Introduction

The JCB 555-70 is the machine for operations that need serious bulk-handling capacity but don’t want to step up to a dedicated wheel loader. Launched in late 2025 alongside the 546-70, it lifts 5.5 tonnes to a 7-metre (23-foot) height — almost 24% more than the 542-70 it sits above, and 31% more by some measures — thanks to an all-new N-shaped boom and uprated axles. Crucially, it does this without growing: it keeps the agility of a 7-metre telehandler, so it still maneuvers confidently in and around prairie farm buildings. For operations regularly stacking large square bales, loading high-sided trailers, handling biomass, or moving big tonnages of grain and muck, the 555-70 takes on jobs that once required a much bigger machine.

On Aglist, the value is in understanding where the 555-70 fits in the agricultural telehandler market, with real owner and operator feedback beside the spec sheet. The numbers tell you what it lifts; the reviews tell you how the N-boom performs under heavy load, how the operator-assist systems work in practice, and how it holds up. It’s a new machine, available in AGRI Xtra and top-spec AGRI Pro.

As with any telehandler, the load chart is the most important thing to understand — how much the machine lifts at a given height and reach. We explain that below.

Configurations & Pricing Context

The 555-70 is a new full-size machine in JCB’s agricultural Loadall range, in the 5.5-tonne class with a 7-metre lift height — the highest-capacity 7-metre Loadall JCB builds. It’s available in AGRI Xtra and top-spec AGRI Pro specifications. All versions come with 160 litre/min load-sensing Smart Hydraulics and DualTech VT transmission — JCB’s award-winning 2-in-1 hydrostatic-and-powershift system with seamless automatic transitions.

AGRI Pro versions add the 50 km/h High Speed DualTech VT for faster travel between yards, fields, and distant buildings, plus automatic four-wheel-drive engagement under braking for shorter stopping distances. Options include Sway Control (a hydraulic levelling system for cross-slopes, on AGRI Xtra and AGRI Pro), IntelliAssist (automated boom and attachment controls, with programmable return-to-dig and return-to-load), IntelliWeigh (integrated real-time load weighing, no calibration required, reporting via LiveLink), and air trailer braking.

Pricing varies by configuration, attachments, and dealer. Because Dmytro has direct knowledge of Saskatchewan dealer and used pricing, we defer to local market figures over manufacturer-advertised numbers.

Key Specifications

Specification	JCB 555-70
Machine class	Full-size agricultural telehandler
Maximum lift capacity	5.5 tonne (~12,125 lb)
Maximum lift height	7.0 m (~23 ft)
Boom	New N-shaped boom
Axles	Uprated
Engine	JCB DieselMAX
Engine power	112 kW (150 hp) / 129 kW (173 hp)
Transmission	DualTech VT (50 km/h on AGRI Pro)
Hydraulics	160 L/min load-sensing Smart Hydraulics
Cab	CommandPlus (69 dBA)
Levelling	Sway Control (optional)
Load weighing	IntelliWeigh (optional)
Telematics	LiveLink (standard)

Specifications are verified against JCB specification data and manufacturer announcements. Confirm exact figures for the specific machine, year, and configuration with your dealer, and always consult the load chart for capacity at a given height and reach.

Understanding the Load Chart (Read This First)

On any telehandler, the load chart is the most important spec to understand — and on a high-capacity machine like the 555-70, it defines what the extra muscle actually gives you.

The 555-70’s headline figures are a 5.5-tonne maximum capacity and a 7-metre lift height — but those don’t happen at the same time. The load chart shows how much the machine lifts safely at every combination of height and forward reach, and capacity drops as the boom extends up and out, because the load moves farther from the machine’s center of gravity. The full 5.5 tonnes is available at low height and close reach; at the full 7-metre height, or at reach, safe capacity is lower.

What the 555-70’s new N-shaped boom and uprated axles deliver is more capacity throughout the working envelope — not just at the headline maximum. That’s what allows it to take on bulk-handling jobs (large square bales, biomass, big grain and muck tonnages) that previously demanded a much larger machine, while keeping the agility of a 7-metre telehandler. Still, match the chart to your tasks: check what it lifts at the height and reach you’ll actually work at. If you regularly handle heavy loads at height, the 555-70’s higher base capacity is exactly the reason to choose it over a 542-70 or 546-70.

Build & Engineering Detail

The 555-70’s defining feature is its all-new N-shaped boom, engineered together with uprated axles to deliver a 5.5-tonne lift capacity — a substantial jump over the 542-70 — while keeping the machine’s footprint agile. The redesigned boom structure (with repositioned compensation rams, twin underslung rams, and a larger lift ram, as across the new range) also increases tear-out and break-out force, so it pushes harder into silage clamps, muck heaps, and grain piles and lifts more when loaded.

Two power packages are offered: AGRI Xtra (150 hp) and top-spec AGRI Pro (173 hp). Both run 160 litre/min load-sensing Smart Hydraulics — regenerative circuit, auto SmoothRide, boom-end damping — and JCB’s DualTech VT transmission, which combines hydrostatic drive (precise low-speed control for yard and attachment work) with powershift (efficient high-speed travel), transitioning automatically. The AGRI Pro’s High Speed DualTech VT reaches 50 km/h, and on the road it runs in rear-wheel drive for acceleration and towing traction, automatically engaging four-wheel drive under braking for the shortest stopping distances.

The CommandPlus cab provides best-in-class space, visibility, and a 69 dBA noise level. IntelliAssist automates repetitive boom movements (return-to-dig, return-to-load); IntelliWeigh weighs loads in real time from hydraulic pressure and boom angle, with no calibration and LiveLink reporting; Sway Control levels the machine on cross-slopes via a chassis-to-front-axle cylinder — all valuable for heavy, repetitive bulk handling on uneven prairie ground.

Best Applications

The 555-70 is a strong fit for:

• Bulk handling without a wheel loader — JCB’s answer for operations needing serious capacity in a telehandler package.
• Large square bale stacking — the 5.5-tonne capacity handles heavy bales at height.
• Loading high-sided trailers with heavy loads — capacity and reach combined.
• Biomass, grain, and muck at volume — moving larger tonnages without stepping up in machine size.

For everyday mixed handling at lower cost, the 546-70 (4.6 tonnes) is the all-rounder; for even greater capacity, the heavy-lift 560-80 (6 tonnes) steps up. The 555-70’s niche is maximum capacity within an agile 7-metre telehandler — taking on jobs that once required a much bigger machine.

How the 555-70 Fits the JCB Loadall Range

The 555-70 is a new model (launched late 2025) and the highest-capacity 7-metre machine in JCB’s agricultural Loadall range, sitting above both the 542-70 and the new 546-70. Its N-shaped boom and uprated axles give it nearly 24% more lift capacity than the 542-70. Above it, only the heavy-lift 560-80 (6 tonnes, 8-metre height) offers more capacity; the high-lift 536-95 trades capacity for a 9.5-metre reach. It’s the choice for operations needing bulk-handling muscle without giving up telehandler agility. Explore the full range on the JCB brand hub.

JCB 555-70 Reviews & Ratings

On Aglist, open the Reviews & Ratings section on this page to see how the 555-70 performs where it matters: lifting capacity under heavy bulk loads, how the new N-shaped boom handles, tear-out force in clamps and piles, the DualTech VT transmission, IntelliWeigh accuracy, cab comfort, and reliability. As a newer machine, owner feedback is especially valuable — if you own a 555-70, your review helps the next prairie buyer.

Frequently Asked Questions

How much can the JCB 555-70 lift? Maximum lift capacity is 5.5 tonnes (about 12,125 lb) to a maximum height of 7 metres (about 23 feet) — nearly 24% more than the 542-70. Full capacity is available at low height and close reach; capacity decreases as the boom extends, so consult the load chart for your specific tasks.

What is the N-shaped boom on the JCB 555-70? An all-new boom design introduced with the 555-70, engineered alongside uprated axles to deliver its 5.5-tonne lift capacity. Combined with repositioned compensation rams and a larger lift ram, it increases lifting power and tear-out force throughout the working range — letting the machine handle bulk jobs that once needed a much bigger machine.

Can the JCB 555-70 replace a wheel loader? For many operations, that’s exactly its purpose. JCB positions it for farms that need more lift capacity without stepping up to a dedicated wheel loader — handling large square bales, biomass, and big tonnages of grain and muck, while retaining a telehandler’s reach, placement precision, and agility around buildings. Whether it fully replaces a loader depends on your bulk-handling volume; check the load chart against your heaviest regular tasks.

What’s the difference between the JCB 555-70 and 546-70? The 555-70 lifts more (5.5 tonnes vs 4.6) with its new N-shaped boom and uprated axles, suited to heavy bulk handling. The 546-70 is the all-rounder for everyday feeding, mucking, bedding, and general handling. Both are new 2025 models with a 7-metre lift height and the same operator-assist options.

What power options does the JCB 555-70 have? Two: AGRI Xtra with 112 kW (150 hp) and top-spec AGRI Pro with 129 kW (173 hp). Both come with 160 litre/min Smart Hydraulics and DualTech VT transmission; the AGRI Pro adds a 50 km/h top speed.

Does the JCB 555-70 have IntelliWeigh? Yes — IntelliWeigh is available as an option. It provides integrated real-time load weighing based on hydraulic pressure and boom angle, allowing accurate loading straight from the cab with no calibration, with load data reported through LiveLink — particularly useful when loading trailers and trucks to precise weights.

Is the JCB 555-70 bigger than other 7-metre Loadalls? It keeps the agility of a 7-metre telehandler despite its much higher capacity — that’s central to its design. The N-shaped boom and uprated axles deliver the extra lift without sacrificing the maneuverability that matters in and around farm buildings.

Should I choose the 555-70 or the heavy-lift 560-80? The 560-80 lifts more (6 tonnes) to a taller 8-metre height, as JCB’s highest-capacity agricultural Loadall. The 555-70 offers 5.5 tonnes at 7 metres in a more agile package. Choose the 560-80 if you need maximum capacity and height; the 555-70 if you want heavy capacity while keeping 7-metre agility.
